Quarrying
Zip It
A quick-to-install, modular overland conveying system makes material handling reconfiguration easy.
In its second season and operating a brand-new processing plant, Dakota Aggregates mines on seven million square meters within the University of Minnesota Outreach, Research and Education Park. Located in Minnesota, USA, the mine serves the Minneapolis metro area with a wide variety of construction aggregate products. The operation was designed with innovation in mind, particularly where material handling is concerned. The site spans five kilometers from north to south, and a two and a half from east to west. Consequently, overland conveyor systems were chosen to efficiently transfer material from the face to the processing facility, while eliminating the costly use and resulting emission streams of loaders and haul trucks; and providing quiet operation while minimizing energy use and lowering operating costs per ton.
Initially, the challenge for Dakota Aggregates was finding a lower cost overland alternative versus that of custom- engineered, conventional overland systems – and most importantly, one that would allow them to easily and quickly reconfigure their overland systems to accommodate changing mining requirements each season.
Dakota Aggregates has a substantial 40-year lease on the university-owned land where melting glaciers had left behind a thick blanket of high-quality sand and gravel thousands of years ago. Mining this deposit is part of an overall sustainability focus. A few of the big benefits of this initiative is that the local region taps into the cost-efficiencies of a valuable and nearby source of aggregate products, while the university realizes an additional long-term revenue source. And, for every ton of gravel mined, a portion of the profit goes into a scholarship fund for geology and civil engineering
students at the university. It’s a win-win deal for all and an example of innovation at its best.
With the latter spirit in mind, Dakota
Aggregates approached its material handling
challenges by consulting with Superior
Industries, a global manufacturer of crushing,
screening, washing and conveying systems. Superior
had recently launched its Zipline® Conveyor, a pre- engineered, modular overland conveying system designed for quick, and almost tool-free installation.
“It was refreshing to share our input on the system with the engineers at Superior and to work with them on various
enhancements to this new product,” says Stacey Hannover, operations manager for the Dakota Aggregates plant, which processes more than 1.4 million tonnes of aggregate products annually.
The site mines from its furthest boundary and back toward the processing plant. “While we are generally pulling conveyors out and shortening the distance of conveying, we can easily add on sections in other areas of the operation. We needed flexibility at the right price point. With the Zipline Conveyor, we have ease of assembly and ease of onsite portability,” says Hannover.
The operation utilizes a total of 1,500-meters of modular conveyor sections (at lengths of 10-feet each and belt widths of 762 to 914mm) which is currently divided into six different overland systems of 150- to up to 300-meters. “It’s easy to reconfigure any one of our modular overland systems to cost- effectively meet our changing requirements each year. As an example, during last season, we easily pulled 75-meters out of one system. Also, while we generally operate on level ground, next season we will be moving a section to accommodate material transfer on an area with a 15-percent incline,” says Hannover. He adds that installation is “pretty much a breeze. Once we got the pattern down, three crew members marched right down the conveyor corridor and were able to assemble 300-meters of overland conveyor sections in a ten-hour day.” The crew used a forklift and a skid steer loader with no need for cranes or other heavy equipment.
